It comes with approximate dimensions of 110 x 131 x 111 millimeters and a weight of about 650 grams. The Hirschmann RS20-2400T1T1SDAUHH Managed Fast Ethernet Switch has an IP 20 rated protection class and a maximum shock rating of 15 g for 11 milliseconds, which is equivalent to 18 shocks.

The tolerable relative humidity range for this managed switch for both operation and storage is from 10 to 95 percent with no condensation. The Hirschmann RS20-2400T1T1SDAUHH Managed Fast Ethernet Switch comes with an operating temperature range of 0 to 60 degrees Celsius, and a storage or transport temperature range from -40 to 70 degrees Celsius. It supports ring as well as star network topologies, and it has a twisted pair (TP) network cable with a length of 0 to 100 meters. The power output rating of this compact OpenRail managed Fast Ethernet switch is 46.1 BTU (IT) per hour in the form of heat. Other specifications of this device include a current consumption rating of 563 Amps at 24 Volts DC, and 282 Amps at 48 Volts DC. It operates on a voltage rating of 12/24/48 Volts DC with 9.6 to 60 Volts DC redundant voltage or with a voltage rating of 24 Volts AC with 18 to 30 Volts AC redundant voltage. The RS20-2400T1T1SDAUHH Managed Fast Ethernet Switch comes with a 6-pin plug-in terminal block interface for the signaling contact and the power supply. This switch features a fanless design, it mounts on a DIN Rail, and it supports the store and forward switching functionalities.
Hirschmann switch r20 series#
It is manufactured as a member of the Hirschmann RS20 series of OpenRail managed switches and it has a total of 24 Fast Ethernet communication ports. The remaining ports can be used either for 100 BASE-TX or as a combination of four SFP trans-ceivers and four TX ports. The Hirschmann RS20-2400T1T1SDAUHH Managed Switch is a compact OpenRail type of managed Fast Ethernet switch. Hirschmann RSP Switches RSP switches from Hirschmann offer eleven ports, three of which can be equipped with SFP transceivers that support Fast (100 BASE-FX) or optionally Gigabit-Ethernet (100/1000 BASE-FX).
